Kamera |
Képérzékelő |
1/3” Progressive Scan CMOS |
Shutter Speed |
1/3 to 1/10000 s |
Slow Shutter |
Yes |
Aperture |
2.8 mm: F1.6 |
4 mm: F1.6 |
Optika |
2.8 mm/ 4 mm |
Lens Mount |
M12 |
Min. szükséges megvilágítás |
Color: 0.005 Lux; 0 Lux with IR/White Light |
Day/Night Mechanism |
IR Cut Filter |
Day/Night Switch |
Unified/ Scheduled/ Auto |
Digital Noise Reduction |
3D DNR |
WDR |
DWDR |
Weatherproof Rating |
IP67 |
Forgatási/döntési szög |
Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360° |
Látószög |
2.8mm: |
Horizontal FOV: 95.7°, Vertical FOV: 51.7°, Diagonal FOV: 113.0° |
4mm: |
Horizontal FOV: 79.7°, Vertical FOV:42.9°, Diagonal FOV: 93.9° |
LENS |
Type |
Fixed Focal Lens |
Focal Length |
2.8 mm/4 mm |
Aperture |
2.8 mm: F1.6 |
4 mm: F1.6 |
FOV |
2.8 mm: |
Horizontal FOV: 95.7°, Vertical FOV: 51.7°, Diagonal FOV: 113.0° |
|
4 mm: |
Horizontal FOV: 79.7°, Vertical FOV: 42.9°, Diagonal FOV: 93.9° |
Lens Mount |
M12 |
DORI Distance |
2.8 mm: |
Detect: 64 m (209 ft) |
Observe: 27 m (87 ft) |
Recognize: 13 m (42 ft) |
Identify: 6 m (21 ft) |
|
4 mm: |
Detect: 80 m (262 ft) |
Observe: 33 m (109 ft) |
Recognize: 16 m (52 ft) |
Identify: 8 m (26 ft) |
Angle Adjustment (Manual) |
Range |
Pan: 0° to 355° |
Tilt: 0° to 75° |
ILLUMINATOR |
IR LED |
Quantity: 1 |
Range: 30m |
Wavelength: 850nm |
White LED |
Quantity: 1 |
Range: 30m |
Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
VIDEO |
Max. Resolution |
2560 × 1440 |
Main Stream |
Frame Rate: |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
|
Resolution: |
2560x1440,2304x1296, 2048x1280, 1920x1080, 1280x720 |
|
|
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Sub-Stream |
Frame Rate: |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
|
Resolution: |
640x480,352x288, 320x240 |
|
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Bit Rate Control |
CBR, VBR |
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264 |
Sub-Stream: H.265/H.264 |
H.264 Type |
Main Profile/High Profile |
H.264+ |
Main Stream Supported |
H.265 Type |
Main Profile |
H.265+ |
Main Stream Supported |
Video Bit Rate |
Main Stream: 256 Kbps to 4 Mbps |
Sub-Stream: 64 Kbps to 512 Kbps |
Image |
Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, |
White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation(90°/270°) |
