Leírás és Paraméterek
CAMERA
Image Sensor 1/2.9” Progressive Scan CMOS
Shutter Speed 1/3 to 1/30000 s
Slow Shutter Yes
Minimum Illumination 0.005 Lux; 0 Lux with IR/White Light
Day/Night Mechanism IR Cut Filter
Day/Night Switch Unified / Scheduled / Auto
LENS
Type Motorized Varifocal Lens
Focal Length 5.2-130 mm (25X Optical Zoom)
Aperture Max. F1.6
FOV • Horizontal FOV: 2.30°-57.06°
• Vertical FOV: 1.31°-32.74°
• Diagonal FOV: 2.63°-65.01
DORI Distance Wide
• D: 351 ft (107 m)
• O: 144 ft (44 m)
• R: 69 ft (21 m)
• I: 36 ft (11 m)
Tele
• D: 8530 ft (2600 m)
• O: 3553 ft (1083 m)
• R: 1706 ft (520 m)
• I: 853 ft (260 m)
PTZ
Pan/tilt Range Pan: 0° to 360°, Tilt: -23.6° to 97.8°
Pan/tilt Speed Pan Speed:
• Configurable from 0° to 160°/s
• Preset Speed: 240°/s
Tilt Speed:
• Configurable from 0° to 120°/s
• Preset Speed: 200°/s
Proportional Pan Yes
Presets 300
Patrol Scan 8 patrols, up to 8 presets for each patrol
Pattern Scan 32 path
Power-off Memory Yes
Park Action Yes
Preset, Patrol Scan, Pattern Scan, Home
Power Up Actions Yes
3D Positioning Yes
PTZ Status Display Yes
Preset Freezing Yes
Scheduled Task Yes
PTZ Protocol Pelco-D, Pelco-P
Angle Adjustment (Manual)
Range Pan: 0° to 360°, Tilt: -23.6° to 97.8°
ILLUMINATOR
Illuminator Type • 2× IR LED
• 2× Integrated Infrared-White LED
IR LED • Quantity: 2
• Range: 328 ft (100 m)†
• Wavelength: 850 nm
Illuminator Distance • IR LED: 100 m (328 ft)†
• White LED: 50 m (164 ft)†
Illuminator On/Off Control Auto/Scheduled/Always on/Always off
Integrated Infrared-White LED • Quantity: 2
• White LED Range: 164 ft (50 m)†
VIDEO
Max. Resolution 2688x1520
Main Stream • Frame Rate:
50Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps, 30fps
• Resolution:
2688x1520, 2560x1440, 2304x1296, 2048x1280
Sub-Stream • Frame Rate:
50Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps, 30fps
• Resolution:
840x480, 704x576, 640x480, 640x360, 352x288, 320x240
Third Stream • Frame Rate:
50Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps,15fps, 20fps, 25fps, 30fps
• Resolution:
1920x1080, 1280x960, 1280x720, 848x480, 704x576
Bit Rate Control CBR, VBR
Video Compression • Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• Third-stream: H.265/H.264/MJPEG
H.264 Type High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile
H.265+ Main Stream Supported
Video Bit Rate • Main Stream: 4096 Kbps to 16384 Kbps
• Sub-Stream: 128 Kbps to 2048 Kbps
• Third Stream: 768 Kbps to 16384 Kbps
Image Settings • Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• IR Light Intensity
• HLC Adjustable
• Low Illuminator
Image Enhancement BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range 120 dB
Defog Digital Defog
Image Stabilization EIS
SNR ? 52 dB
Image Parameters Switch Yes
Privacy Mask Up to 4 Masks
ROI 8 Regions
OSD Setting Yes
AUDIO
Audio Communication Two-Way Audio
Audio Input Built-in Microphone
Audio In Interface
Audio Output Built-in Speaker
Audio Out Interface
Audio Compression Yes
Audio Sampling Rate 8 KHz
Environment Noise Filtering Yes
Audio Bit Rate 64 Kbps(G.711 alaw)
NETWORK
Protocol TCP/IP, UDP, ICMP, ARP, SNMP, SMTP, RTMP, HTTP, HTTPS, DHCP, DNS, RTSP, RTP, NTP, IPv4, IPv6, UPnP, SSL/TLS, FTP/SFTP
ONVIF Yes
API Open Network Video Interface (Profile G/S/T)
Simultaneous Live View 3 Main Streams & 3 Sub-Streams & 3 Third-streams
Client VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Web Browser • Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above
Cloud Yes
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication
ALARM AND EVENT MANAGEMENT
Smart Event • Intrusion Detection
• Line Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Loitering Detection
• Human Detection
• Vehicle Detection
• Abnormal Sound Detection
• Scene Change Detection
Basic Event • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
• Camera Tampering
• Exception (Illegal Login)
Alarm Linkage • Memory Card Video Recording
• Upload Capture
• Alarm Output Device
• Push Notifications
• Send to Alarm Server
• Active Defence-Sound Alarm
• Active Defence-Light Alarm
• Email Alarm
• Smart Tracking
Smart Tracking • Intelligent Auto Tracking (Human/Vehicle/Event-Triggered)
• Manual Tracking (Joystick Support)
Deep Learning Function
People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.‡
INTERFACES
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm 2 Alarm In, 1 Alarm Out
Red/Blue Warning Lights
Reset Button Yes
Power DC Power Port
RS-485 Port Yes
On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*
Built-in Microphone Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker Yes
Audio 1 Audio In, 1 Audio Out
GENERAL
Operating Temperature -30 °C to 65 °C (-22 °F to 149 °F)
Storage Temperature -40 °C to 65 °C (-40 °F to 149 °F)
Operating Humidity 95% or Less (Non-Condensing)
Storage Humidity 95% or Less (Non-Condensing)
Package Content • VIGI Network Camera
• Installation Guide
• Waterproof Cable Attachments
• Mounting Accessories
Material Metal
Net Weight 2.8 kg
Power Supply DC
• 12V DC ± 5%, Max. 21.6 W, 5.5 mm Coaxial Power Plug
• Recommended Power Supply:
PoE
• PoE: 802.3at, Class 4, Max. 24.7 W
ErP Information
• Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 9.2W
Protection • IP66 Weatherproof
• IK08 Vandal-Proof
• 6 kV Lightning Protection
Product Dimensions (L x W x H) ?6.3 × 10.6 in (?160 × 270 mm)
Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IP66, IK08, ONVIF
Specifikációk:
Kialakítás: PT / PTZ
Felbontás: 4MP
Vandálbiztos kivitel: Van
Lencse: 5-130
Segéd fény távolság: 100
SD kártya támogatás: Van
Segéd fény: Hibrid
Elhelyezés: Kültéri
Hang: Beépített Mikrofon és hangszóró
Tápellátás: DC / PoE
