Leírás és Paraméterek
Compatibility | Intel LGA1954/1851/1700/1200/1151/1150/1155/1156 AMD AM5/AM4 |
|
TDP | 260W |
|
Overall Dimension | 133×122×160mm (L×W×H) |
|
Heatsink Material | 6×?6mm Heatpipe + Copper Base + Aluminum Fin |
|
Weight | 1300g (heatsink+fan) |
|
| Front Fan | Middle Fan |
Fan Model | AF-120 SLIM | AM-120-K |
Fan Dimension | 120×120×15mm | 120×120×25mm |
Fan Speed | 500 ~ 1850±10% RPM | 0 ~ 2500±10% RPM |
Max. Air Flow | 65.2CFM | 79.7CFM |
Max. Static Pressure | 1.36mmH2O | 3.65mmH2O |
Noise | 33.9dB(A) Max. | 31.0dB(A) Max. |
Rated Voltage | 12VDC | 12VDC |
Operating Voltage | 10.8 ~ 13.2VDC | 10.8 ~ 13.2VDC |
Started Voltage | 7VDC | 7VDC |
Rated Current | 0.28A | 0.25A(0.3A Max.) |
Power Input | 3.36W | 3.6W Max. |
Bearing Type | Hydraulic Bearing | Hydraulic Bearing |
Connector | 4Pin PWM | 4Pin PWM |
EAN | 6931393308678 |
Specifikációk:
Tipus: Processzor hűtő
Hűtési mód: Levegő
Méret: 12
Processzor foglalat: Univerzális (LGA1700 kompatibilis)
Max. Zajszint: 33.9
Levegőkeringetés: 110.77
