Leírás és Paraméterek
Connector Type |
|
Category | Cat 6 |
Type | 8P8C (Eight Position, Eight Contact) |
Shielding | UTP (Unshielded Twisted Pair) |
|
|
Material |
|
Housing Material | Polycarbonate |
Contact Material | Copper |
Contact Surface Material | Gold Plating on Nickel Barrier |
Gold Plating Thickness | 50U (50μin or 1.27 µm) |
|
|
Electrical Properties |
|
Voltage/Current Rating | 125 VAC / 1.5 A |
Insulation Resistance | ≥ 500 MΩ |
Contact Resistance | ≤ 20 mΩ |
Dielectric Withstand Voltage | 750 V DC/AC Peak |
|
|
Mechanical Properties |
|
Durability | ≥ 1250 mating cycles, ≥ 250 termination cycles |
Wire Diameter | ODO ≤ 6.6 mm |
|
|
Environment |
|
Operating Temperature | -40°C to 70°C |
Operating Humidity | RH 10% to 90% (non-condensing) |
Storage Temperature | -40°C to 80°C |
Storage Humidity | RH 5% to 96% (non-condensing) |
|
|
General |
|
Dimension | 53x18x15 mm (LxWxH) |
Net Weight | 6.1 g |
Specifikációk:
Típus: Átalakító/Csatlakozó/Törésgátló
